VISCOFLUX Mobile S
Efficiently transfer highly viscous, paste-like and non-flowing media from drums. Discover how VISCOFLUX mobile S empties demanding media safely, flexibly and with minimal product loss.
- Reduce residual quantities to less than one percent
- Prevent contamination through a closed transfer process
- Transfer sensitive and paste-like media gently
- Use the system flexibly at different locations
Features
- Mobile and Compact Drum Emptying System
- Designed for use in hygienic environments
- Process unit made of stainless steel
- Electronics and battery are moisture-sealed
- Low-dead-space design with IP 66 protection rating
- Two chassis options available: narrow or wide
- Suitable for standard drums, conical drums, and cardboard drums
- Can also be used with shipping container drums equipped with an aseptic bag
- Suitable for drums with typical transport dents
- Motor, pump, support plate, and process seal can be customized
- Pump, follow-up plate, and process seal available in FOOD version
- Eccentric screw pump for low-shear, low-turbulence pumping
- The motor can remain on the process unit during pump cleaning
- Pumps available with a pulse generator for non-contact flow measurement
Advantages
- Pumps difficult, high-viscosity fluids directly from the drum
- Empties drums with residual quantities of less than 1%
- Increases process reliability when handling sensitive media
- Enables flexible use in different locations
- Takes up little space in the production environment
- Supports hygienic processes in the food, pharmaceutical, and cosmetics industries
- Can be quickly cleaned and disassembled
- Protects the medium through low-shear conveyance
- Suitable for various types of drums and containers
- Easy to operate during daily use
- Offers various control options for the process
Technical Specifications
| Feature | Specification |
|---|---|
| Delivery pressure | max. 15 bar |
| Viscosity | up to 500,000 mPas |
| Fluids | High-viscosity media that are just barely flowable, non-self-flowing media |
| Process unit | Battery-powered, made entirely of stainless steel, IP 66, load capacity up to 100 kg, chassis available in two standard sizes |
| For drum diameters | 560 mm or 571 mm |
| For conical drums | 550 mm at the top, 515 mm at the bottom |
| For drums with a small opening | Ø 540 mm at the top, Ø 571 mm at the bottom |
| Pumps | Ø 53 mm, lengths 1,000 mm and 1,200 mm |
| Pump type | VISCOPOWER F 580 |
| Versions | Also available in food-grade versions, compliant with EC 1935/2004 and FDA CFR 21 |
| Motors | Three-phase motors starting at 0.75 kW, helical gearmotors, air motors |
| Process seal | NBR compliant with EC 1935/2004, FDA-compliant, or FKM |
| Power supply | For motor or control box |
| Fittings | Ball valves for compressed air supply and venting |
Drive unit
| Feature | Specification |
|---|---|
| Battery | Lead-acid 24 V / 9 Ah, maintenance-free |
| Charging | Via separate charger |
| Supply voltage | 100–240 V AC, 50/60 Hz |
| Charging time | 4–6 hours with a fully discharged battery |
Process device
| Feature | Specification |
|---|---|
| Protection class | IP 66 |
| Compressed air supply | 6–8 bar, dry |
| Pump motor | FPM 6 or FPM 8 |
| Air consumption FPM 6 | 1,500 l/min at 6 bar flow pressure |
| Air consumption FPM 8 | 2,400 l/min at 6 bar flow pressure |
VISCOFLUX mobile S or HF?
The HF version extends the range of applications covered by the VISCOFLUX family. It is particularly suitable for applications where a high flow rate and low overall system height are key priorities. For applications requiring frequent complete disassembly and quick, straightforward pump cleaning, the VISCOFLUX mobile S is the ideal choice.
| Feature | VISCOFLUX mobile S | VISCOFLUX mobile HF |
|---|---|---|
 |
 |
|
| Design focus | Easy disassembly and cleaning | Maximum flow rate |
| Flow rate* | Max. 25 l/min | Max. 50 l/min; up to 70 l/min with frequency inverter |
| Emptying a 200-litre drum* | Approx. 8 minutes pumping time | Approx. 3–4 minutes pumping time |
| Speed | Approx. 700 rpm | 257 rpm at 50 Hz; 311 rpm at 60 Hz |
| Extended height | Max. 3.150 m | 2.707 m with standard motor; 2.805 m with stainless-steel motor |
| Cleaning | Easy to disassemble and clean | Cleaning connection provided; complete disassembly requires more effort |
| Batch filling | Contactless control via speed controller | Possible with an FMO flow meter |
| Request a Quote | View Viscoflux mobile HF |
* Comparative value based on triple-concentrated tomato paste. The actual flow rate depends on the fluid, temperature, hose routing and system configuration. Drum changeover times are not included.
